基于Prometheus的remote_write 特性的数据采集
收集后端
- proto定义，来源于Prometheus源码 remote.proto
// Copyright 2016 Prometheus Team
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
syntax = "proto3";
package prometheus;
option go_package = "prompb";
import "types.proto";
import "gogoproto/gogo.proto";
message WriteRequest {
repeated prometheus.TimeSeries timeseries = 1 [(gogoproto.nullable) = false];
}
message ReadRequest {
repeated Query queries = 1;
}
message ReadResponse {
// In same order as the request's queries.
repeated QueryResult results = 1;
}
message Query {
int64 start_timestamp_ms = 1;
int64 end_timestamp_ms = 2;
repeated prometheus.LabelMatcher matchers = 3;
prometheus.ReadHints hints = 4;
}
message QueryResult {
// Samples within a time series must be ordered by time.
repeated prometheus.TimeSeries timeseries = 1;
}
types.proto
// Copyright 2017 Prometheus Team
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
syntax = "proto3";
package prometheus;
option go_package = "prompb";
import "gogoproto/gogo.proto";
message Sample {
double value = 1;
int64 timestamp = 2;
}
message TimeSeries {
repeated Label labels = 1 [(gogoproto.nullable) = false];
repeated Sample samples = 2 [(gogoproto.nullable) = false];
}
message Label {
string name = 1;
string value = 2;
}
message Labels {
repeated Label labels = 1 [(gogoproto.nullable) = false];
}
// Matcher specifies a rule, which can match or set of labels or not.
message LabelMatcher {
enum Type {
EQ = 0;
NEQ = 1;
RE = 2;
NRE = 3;
}
Type type = 1;
string name = 2;
string value = 3;
}
message ReadHints {
int64 step_ms = 1; // Query step size in milliseconds.
string func = 2; // String representation of surrounding function or aggregation.
int64 start_ms = 3; // Start time in milliseconds.
int64 end_ms = 4; // End time in milliseconds.
}
- 创建/write接口
package io.prometheus.remote;
import java.io.IOException;
import java.text.SimpleDateFormat;
import java.util.Arrays;
import java.util.Date;
import java.util.Iterator;
import java.util.List;
import java.util.Map;
import java.util.concurrent.ExecutionException;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;
import java.util.stream.Collectors;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.kafka.core.KafkaTemplate;
import org.springframework.kafka.support.SendResult;
import org.springframework.util.concurrent.ListenableFuture;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.ResponseStatus;
import org.springframework.web.bind.annotation.RestController;
import org.xerial.snappy.Snappy;
import com.google.protobuf.InvalidProtocolBufferException;
import com.google.protobuf.util.JsonFormat;
import io.prometheus.remote.kafka.KafkaTopicConfig;
import prometheus.Remote.WriteRequest;
import prometheus.Types.Label;
import prometheus.Types.Sample;
import prometheus.Types.TimeSeries;
@RestController
public class RemoteController {
static Logger logger = LoggerFactory.getLogger(RemoteController.class);
// @Autowired
private KafkaTopicConfig kafkaTopicConfig;
// @Autowired
private KafkaTemplate<String, String> kafkaTemplate;
@RequestMapping(method = RequestMethod.POST, value = "/write")
public void write(@RequestBody byte[] byteArray) throws IOException {
WriteRequest wr = WriteRequest.parseFrom(Snappy.uncompress(byteArray));
logger.info(JsonFormat.printer().print(wr));
List<TimeSeries> tsl = wr.getTimeseriesList();
for (TimeSeries ts : tsl) {
Map<String, String> lm = ts.getLabelsList().stream()
.collect(Collectors.toMap(Label::getName, Label::getValue));
List<Sample> ls = ts.getSamplesList();
for (Sample s : ls) {
String timestamp = new SimpleDateFormat("yyyy-MM-dd'T'HH:mm:ssXXX")
.format(new Date(s.getTimestamp()));
String name = lm.get("__name__");
String value = String.valueOf(s.getValue());
logger.info("Sample: timestamp=" + timestamp + ", name=" + name + ", value=" + value + ", labels=" + mapAsString(lm));
}
}
}
private String mapAsString(Map<String, String> map) {
String mapAsString = map.keySet().stream()
.map(key -> key + "=" + map.get(key))
.collect(Collectors.joining(", ", "{", "}"));
return mapAsString;
}
}
新增收集配置
修改promethus.yml，新增remote_write的配置，如下的demo
global:
scrape_interval: 15s # By default, scrape targets every 15 seconds.
# Attach these labels to any time series or alerts when communicating with
# external systems (federation, remote storage, Alertmanager).
external_labels:
monitor: 'codelab-monitor'
# A scrape configuration containing exactly one endpoint to scrape:
# Here it's Prometheus itself.
scrape_configs:
# The job name is added as a label `job=<job_name>` to any timeseries scraped from this config.
- job_name: 'prometheus'
# Override the global default and scrape targets from this job every 5 seconds.
scrape_interval: 5s
static_configs:
- targets: ['localhost:9090']
remote_write:
- url: "http://host.docker.internal:8080/write"
收集样例
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=prometheus_wal_watcher_notifications_skipped_total, value=128.0, labels={instance=localhost:9090, __name__=prometheus_wal_watcher_notifications_skipped_total, monitor=codelab-monitor, job=prometheus, consumer=35dd99}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=prometheus_wal_watcher_record_decode_failures_total, value=0.0, labels={instance=localhost:9090, __name__=prometheus_wal_watcher_record_decode_failures_total, monitor=codelab-monitor, job=prometheus, consumer=35dd99}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=prometheus_wal_watcher_records_read_total, value=367.0, labels={instance=localhost:9090, __name__=prometheus_wal_watcher_records_read_total, monitor=codelab-monitor, type=samples, job=prometheus, consumer=35dd99}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=prometheus_wal_watcher_records_read_total, value=3.0, labels={instance=localhost:9090, __name__=prometheus_wal_watcher_records_read_total, monitor=codelab-monitor, type=series, job=prometheus, consumer=35dd99}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=prometheus_wal_watcher_samples_sent_pre_tailing_total, value=0.0, labels={instance=localhost:9090, __name__=prometheus_wal_watcher_samples_sent_pre_tailing_total, monitor=codelab-monitor, job=prometheus, consumer=35dd99}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=prometheus_web_federation_errors_total, value=0.0, labels={instance=localhost:9090, __name__=prometheus_web_federation_errors_total, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=prometheus_web_federation_warnings_total, value=0.0, labels={instance=localhost:9090, __name__=prometheus_web_federation_warnings_total, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=promhttp_metric_handler_requests_in_flight, value=1.0, labels={instance=localhost:9090, __name__=promhttp_metric_handler_requests_in_flight, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=promhttp_metric_handler_requests_total, value=367.0, labels={instance=localhost:9090, code=200, __name__=promhttp_metric_handler_requests_total, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=promhttp_metric_handler_requests_total, value=0.0, labels={instance=localhost:9090, code=500, __name__=promhttp_metric_handler_requests_total, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=promhttp_metric_handler_requests_total, value=0.0, labels={instance=localhost:9090, code=503, __name__=promhttp_metric_handler_requests_total, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=up, value=1.0, labels={instance=localhost:9090, __name__=up, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=scrape_duration_seconds, value=0.010108583, labels={instance=localhost:9090, __name__=scrape_duration_seconds, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=scrape_samples_scraped, value=586.0, labels={instance=localhost:9090, __name__=scrape_samples_scraped, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=scrape_samples_post_metric_relabeling, value=586.0, labels={instance=localhost:9090, __name__=scrape_samples_post_metric_relabeling, monitor=codelab-monitor, job=prometheus}
2024-08-01 14:58:29 [INFO ] |io.prometheus.remote.RemoteController| - Sample: timestamp=2024-08-01T14:58:28+08:00, name=scrape_series_added, value=0.0, labels={instance=localhost:9090, __name__=scrape_series_added, monitor=codelab-monitor, job=prometheus}
